Overview
- Steel Basket
- coated pap
- including protective grille and mounting ring
- For 45liters ventilated or closed 25 l
Technical Data
-
Recommended volume (sealed): 25-30 Liter
-
DC resistance (Rdc): 3,56 Ω (serial)
-
Nominal impedance (ZN): 2×2 Ω
-
Resonance frequency (Fs): 26,5 Hz
-
Voice coil diameter: 2,5 inch
-
Voice coil height: 30 mm
-
Mechanical Q factor (Qms): 5,64
-
Electrical Q factor (Qes): 0,49
-
Total Q factor (Qts): 0,45
-
Moving mass (md): 183,6 g
-
Effective piston area (sm): 551,5 cm2
-
Mechanical resistance (Rms): 5,42 kg/s
-
Compliance (Cms): 0,197
-
Force factor (BL): 11,17 Tm
-
Equivalent air volume (Vas): 61,5 dm3
-
SPL 2,83V/1m: 89,02 dB
-
External diameter: 330 mm
-
Installation diameter: 305 mm
-
Installation depth: 100 mm
