OVERVIEW:
- NEXT LEVEL System
- Sand-coated paper membrane
- Made in Germany
SPECIFICATIONS:
-
DC resistance (Rdc): 2,6 Ω
-
Nominal impedance (ZN): 3 Ω
-
Resonance frequency (fs): 91,4 Hz
-
Voice coil diameter: 25 mm
-
Dome/Kalotte: Paper (sand Coated)
-
Cut-off Frequency / Trennfrequenz>:
> 320 Hz 12 dB/Oct
> 270 Hz 18 dB/Oct
