OVERVIEW
- 4-channel amplifier Class A/B
- High-level with auto sense
- Double side PCB and
- SMD components
- Optional remote control module
POWER OUTPUT
-
RMS power, 4 Ohm: 4 x 105 Watts
-
RMS power, 4 Ohm gebrückt: 2 x 300 Watts
SPECIFICATIONS
-
Thermal protection: 80 °C
-
THD @ 4 Ω / 50% Pmax: 0.25 %
-
Signal/noise: 99 dB
-
Band width +- 1 dB: 20 – 20000 Hz
-
Input sensitivity: 0.2 – 10 Vrms
-
Low input impedance: 5k Ω
-
High input impedance: 50 Ω (with RC-HLT)
-
Damping @ 1000 Hz: 65
-
Power consumption, idle: 0.96 A
-
Power cons. 4 Ω stereo: 45 A
-
Power cons. 2 Ω mono: 48 A
-
Weight: 3,3 kg
-
Dimensions: Length: 357 mm x Width: 150 mm x Height: 50 mm
