FEATURES
- 6 channel input
- 8 channel output
- DSP Technology made by cooperation MOSCONI-GLADEN
- Designed and made by MOSCONI, Italy
- Click here to download the latest version of the Software
SPECIFICATIONS
| Input Mode: | Low Level {LL} / High Level {HL} |
| Input Impedance: |
12Kohm (LL) / 47ohm (HL) |
| Input Sensitivity: |
1.2 – 8 Vrms (LL) / 3 – 20Vrms (HL) |
| Input Voltage Regulation: |
-16.5dB ÷ 0dB |
| Max Output Signal: | 8Vrms |
| Output Impedance: | 56 ohm |
| T.H.D. Distortion: | <0.003% @ 4Vrms |
| Frequency Response: |
10Hz-20Khz |
| Channel Separation: |
>90dB (@100Hz) |
| Supply Voltage: | 10V ÷ 16V DC |
| Autosense: | Off / BTL / SE |
| Remote Output: | 100mA max |
| Communication Peripherals: | USB, RCD/RC-Mini (optional), MOS-BTM (optional) |
| Size |
150x125x40mm (including fixed feet) |
