OVERVIEW
- 4-channel amplifier Class A/B
- High-level with auto sense
- Double side PCB and
- SMD components
POWER OUTPUT
-
RMS power, 4 ohms (channel 1 – 4): 4 x 68 Watts
-
RMS power, 4 Ohm bridged: 2 x 210 Watts
SPECIFICATIONS
-
Thermal protection: 80 °C
-
THD @ 4 Ω / 50% Pmax: 0.5 %
-
Signal/noise: 95 dB
-
Band width +- 1 dB: 20 – 20000 Hz
-
Input sensitivity: 0.2 – 10 Vrms
-
Low input impedance: 5 kΩ
-
High input impedance: 50 Ω (with RC-HLT)
-
Damping @ 80 Hz: 50
-
Power consumption, idle: 0.75 A
-
Power cons. 4 Ω stereo: 29 A
-
Power cons. 4 Ω bridged: 47 A
-
Power cons. 2 Ω stereo: 47 A
-
Weight: 2.2 kg
-
Dimensions: Length: 283 mm x Width: 150 mm x Height: 50 mm
